1. Computer 조작이 가장 간단하고 편리한 소프트웨어
2. User의 독특한 사양에 신속 . 정확하게 S/W변경가능
3. Operator의 시청각을 최대한 활용하는 System
4. 무한정한 DATA BACK UP
5. 거래처, 제품명, 모든 Cord 및 입출력 한글화 및 다양한 Option










Model No. LC-2224Serise(A&D in Japan) LC-8217 Serise(A&D in Korea)
Rated capacity 10,20,30,40,50tf 10,215,25tf
Rated output 2mV/V ±0.1% 2mV/V ±0.004mV/V
Maximum safe overload : 200% of rated capacity
150% of rated capacity
Combined error ±0.02% of rated output ±0.03% of rated output/30min
Zero balance ±1% of rated output ±0.02% of rated output
Compensated temperature range -20℃ ~ +60℃ / -4°F ~ +140°F -20℃ ~ +80℃
Recommended excitation voltage 12V 12V
Maximum excitation voltage 15V 15V
Input terminal resistance 410Ω±30Ω 800Ω±40Ω
Output terminal resistance 350Ω±3.5Ω 700Ω±7Ω
nsulation resistance Greater than 5000MΩ at DC50V Greater than 5000MΩ at DC50V
Temperature effect Zero -- 0.007% of rated output/℃ Zero -- 0.03% of rated output/10℃
Span -- 0.002% of rated output/℃ Typ Span -- 0.015% of rated output/10℃
Cable length 10m 32.8tf 10m
